Product Type

Zoom Bullet

Maximum Resolution

6MP

Application Environment

Outdoor

Image Sensor

Progressive Scan CMOS

Sensor Size

1/2.7 "

Day / Night

Yes

Low Light Sensitivity

Superior

Minimum Illumination

Color: 0.01 lux; B/W: 0 lux (IR LED on)

Color to B/W Switch

ISP based switch, configurable

Mechanical IR Cut Filter

Yes

IR LED

IR LED x 4 (850 nm)

IR Working Distance

85m (1.0 lux)

Electronic Shutter

1/30-1/64000 second (auto mode)

Focal Length

Zoom, f2.7-13.5mm

Aperture

F1.6

Zoom Ratio

5x optical

Zoom Application

Camera Installation

Focus

Auto focus

Lens Mount

Board mount

Horizontal Viewing Angle

82.2° - 28.7°

Vertical Viewing Angle

54.5° - 19°

Compression

H.265, H.264 (Main/ High profile), MJPEG

Maximum Frame Rate vs. Resolution

20 fps at 3072 x 2048
20 fps at 2592 x 1944
25 fps at 2688 x 1520
30 fps at 2560 x 1440
30 fps at 1920 x 1080
30 fps at 1280 x 960
30 fps at 1280 x 720
30 fps at 640 x 480

Multi-Streaming

Simultaneous quad streams

Bit Rate

128Kbps - 12Mbps (per stream)

Bit Rate Mode

Constant, Variable

Wide Dynamic Range

Extreme WDR (150 dB)

Image Enhancement

White Balance, Backlight compensation (BLC), Brightness, Contrast, Sharpness, Automatic gain control

Digital Noise Reduction

2D + 3D DNR

Privacy Mask

4 configurable regions

Text Overlay

Yes

Built-in Analytics

Tampering Detection, Face Detection, Object Line Crossing Detection, Object Enter Area Detection

Server-based Analytics

Object Line Counting, People Counting, Face Detection, Object Based Motion Detection, Tamper, Object Line Crossing Detection, Object Enter Area Detection, Missing Object Detection, Unattended Object Detection, Smoke Detection, Heat Map, Dwell Time, Direction Detection, Automatic License Plate Recognition, People Queue Detection, (Require PC-based or standalone IVS or ALPR Server. Contact ACTi support for recommendations on how to maximize analytical accuracy)

Image Orientation

Flip, Mirror, Rotation

Audio Type

2-way, Line-in, Line-out

Audio Compression

G.711

Network Protocol & Service

IPv4/v6, TCP, UDP, DHCP, PPPoE, HTTP, HTTPS, DNS, DDNS, NTP, RTP, RTSP, RTCP, SMTP, FTP, IGMP, ICMP, ARP, Bonjour, UPnP, QoS, SNMP, IEEE 802.1X

Ethernet Port

1 x Ethernet (10/100 Base-T), RJ-45 pigtail connector

Security

IP address filtering, HTTPS encryption, Password protected user level, Anonymous login, IEEE 802.1X network access control

Event Trigger

Video motion detection (10 included and excluded polygons regions), External device through digital input, Sound detection, Intelligent event detection

Event Response

Notify control center, Change camera settings, Command other devices, E-mail notification with snapshots, Play the audio file, Push notification to mobile device, Save video to local storage, Upload video to NVR server, Upload video or snapshot to FTP server, Activate external device through digital output

Unified Solution

Fully compatible with ACTi software

GPS Position

Manual setting

ONVIF Compliant

Yes, Profile S, Profile G, Profile Q, Profile T

GB28181 Compliant

Yes

Web Browser

IE 11

Auto Firmware Upgrade

Yes

Audio Interface

1/1, Terminal block

Analog Video Output

1 x NTSC (or PAL) composite, BNC connector

Local Storage

MicroSD, MicroSDHC, MicroSDXC Memory Card Slot (card not included, up to 128GB)

Digital Input/Output

1/1 (Terminal block)

Power Source

DC 12V, PoE Class 4 (IEEE802.3at)

Power Consumption

14.5 W (DC), 18 W (PoE)

Weight

1272g (2.804lb)

Dimensions

(Ø x L): 105.1mm x 297.5mm (4.1" x 11.7")

Environmental Casing

Weatherproof (IP68), Vandal proof metal casing (IK10)

Bundled Accessories

Integrated bracket

Mount Type

Integrated Bracket, Pole Mount

Operating Temperature

-30°C ~ 60°C (-22°F ~ 140°F)

Operating Humidity

10% - 95% RH

Approvals

CE Class B, FCC Class B, IP68, NEMA 4X, IK10 (metal casing)

Material

Metal

Warranty

3 Year(s). For extended warranty offering, see http://www.acti.com/support/warranty
